Product datasheet - YCSK-6

Split bolt connector, brass

Item number:YCSK-6 (EAN: 5997374186148)

Technical data 1,5-6mm2

More than 100 pc(s) in stock
Net
1.69737 EUR
Gross 2.15566 EUR
Print datasheet
  • Documents
Material of connecting element: From tinned copper
  • Product Review
Material conductor:
Copper
With insulation:
No
Voltage level:
Other
Nominal current:
41 A
Number of screws:
1
Degree of protection (IP):
IP00
Warranty:
2 year
  • More information
Material of connecting element: From tinned copper
Terminal capacity
H
(mm)
C
(mm)
B (a/f) (mm)
D (a/f) (mm)
F
(mm)
Thread
YCSK-6
1,5 – 6
24
3,2
10
12,7
6,5
M12

Dimensional drawing
